Some Tips on How to Use the Golf Cart Battery.

Some Tips on How to Use the Golf Cart Battery.

Thanks Randy for giving us some inspiration for today's tutorial.

What is the normal state of the battery?

If your golf cart battery is shown below (36V 105Ah Golf Cart Battery & 48V Golf Cart Battery), it means that the battery is in good condition.

Golf Cart Battery LCD Display Page 1

Golf Cart Battery LCD Display Page 2

Golf Cart Battery LCD Display Page 3

What counts as an exception? How should we deal with it?

1. LCD Display Page 1 Shows Sleep Mode

Golf Cart Battery LCD Display Sleep Mode

Under what circumstances will hibernation occur?

1. When charging, turn off the discharge switch, Page 2 will appear in Lock state, and Page 1 will display sleep mode.

2. When discharging, turn off the charging switch, Page2 will display the Lock state, and Page1 will display the sleep mode.
3. If the battery switch or the charging and discharging switch is not fully turned on, the Lock state will appear, and Page1 will display the sleep mode.

The details are shown in the figure below:

Golf Cart Battery LCD Display Mode

What should I do if all your switches are turned on, but Lock is still displayed?

1. First, please make sure that the battery switch is turned on;
2. Try to turn off DSG & CHG, and then return to Page1 to check the status. At this time, Page1 will still display the sleep mode, and then return to Page2 to turn on the DSG & CHG switch. After repeating the above actions 2-3 times, Lock will become Normal;
3. If the Normal status display is not restored after trying the above steps, please try to charge the battery, turn off the main switch of the battery, wait for 15S and then restart. try to click Page3 to check the battery cell voltage. If the difference between the highest and lowest voltage of each cell exceeds 100mv, please contact us.

As shown below:

Golf Cart Battery Switch Button

Golf Cart Battery LCD Display Lock2

Video display solution tutorial:

 https://cdn.shopify.com/videos/c/o/v/18aa2aba3db649459798dfdd6222a76e.mp4

Golf Cart Battery Connection Diagram

Some people have connected the golf cart to the battery, but there is no movement on the cart. Please pay attention to the correct connection method and check whether your golf cart needs an additional 12V CONVERTER.

Golf Cart Battery Connection Diagram

If you still have questions about our batteries after reading the above tutorial, please feel free to contact us. We are always working hard to bring convenience to you. We hope you can provide us with valuable suggestions. Innovation is our constant pursuit.
